Salient Features (Hatcher)
- Choice of Capacities
- Possesses all internal components for the safety
of food materials
- Floor space free from obstacles for easy cleaning
- Provides excellent ventilation for eggs and chicks
- Steel Trolly, Light, in weight but Robust.
THERMOMETERS & HYGROMETERS
Calibrated Thermometers of highest accuracy installed behind glass window for reading Temperature and Humidity in the cabinet. Easily, without opening the doors.
HATCHER BASKET
Hatcher Baskets are made of high grade Plastic for durability and resistence to sanitise modren chemicals.
Adequate Ventilation
Easier to handle
Ideal delivery for chicks
Reduced labour and costCONTROLS
Control Panel provided, on front for quick accessability and to operate machine easily.
-
ELECTRICAL
220-250 VAC Fan Motor 1/3 -3/4 HP 4 Heaters, each of 500 watts (per compartment) Electrical requirement for a machine is approx. 3 KW for a Hatcher. When the Hatcher has once acquired its working Temperature, the electric, requirement will be 1-2 KW per compartment.
HUMIDSTAT
Contact Thermometers operates automatically to control the solenoid valve for regulating water flow for humidifier and cooling system. Life long STAINLESS STEEL humidity guard provided.
ALARM BELL
Electronic horn is provided for indicating rise or fall in Temperature or failure of electric supply.
CABINET
The cabinet wall panels are made of fibre with thermocol insulation within and Trollies of thick iron painted with synthetic & with rust proof bolts and nuts. Machines can be dismantled to facilitate their passages through a normal size door.
COOLING SYSTEM
Automatic Cooling System comprising copper pipes and controlled by thermostat through solenoid valve, is provided.
